FlashForge Adventurer 4: With A Nozzle Changeable in 3 Sec & Leveling-free
FOne of Flashforge's latest printers with the goal of a very easy-to-use and powerful 3D printer for home school and office users: Adventurer 4 (AD4). FlashForge AD4 has following features:
o Using a larger filament spool (1kg) from its closed chamber,
o Protecting the user against harmful substances and bad odors in indoor environments with HEPA 13 filter
o Ability to resume printing after power outage
o Built-in camera
o Larger print volume (220 x 200 x 250 mm).However, the most striking features of the product are the nozzle structure with rapid heating (max 265℃ hot-end), reaching 200℃ in just 60 seconds. In addition, this structure has 3 different extruders (0.3/0.4/0.6mm) that can be changed in just 3 seconds depending on the printing requirement via the clips on the sides (must be supplied separately)! There is no need to use a tool during this process and maintenance costs are considerably reduced thanks to the easy operation!
Another important feature is that the platform infrastructure created with precision cutting and super thin plates calibrates itself in a few keys and gives a perfect first layer output (leveling-free). Thus, the difference between any two parts of the whole structure is at most 15mm.
Other Features of FlashForge Adventurer 4
Magnetic, removable print platform: The created models can be separated from the plate within 5 seconds by gently bending the platen.
Isolated Printing Process: The printing process in FF AD4 takes place in a completely closed printing room and the HEPA H13 filter filters 99% of the TVOC dust formed inside and the bad smell of the active carbon filter!
The AD4 filaments are 1kg and are held in the filament cabinet.
The Adventurer 4 excels in 3D printing with ABS, PLA, PC, PETG, PLA-CF, PETG-CF and other materials. Except for Flashforge brand, eSUN, ColorFabb etc. It is also compatible with third-party filaments.
All forms of continuous operation on this printer:
When the system is energized again after a power failure, you can continue printing from where you left off. All you have to do is press "Yes" on the screen!
In addition, after you transfer your model to the device via usb or ethernet, the model is memorized by Adventurer 4 and printing continues even if the internet is cut off or taken from the usb stick slot!
You can also go to pause and change the printing parameters at any time!With the FF AD4 you have many functions to monitor and control your printing status:
o Detection sensor for lack of filament...
o HD Internal camera monitoring...
o Remote printing control via Wi-Fi or Ethernet...
o New FlashPrint program supports multi-device online control by managing printers with high efficiency.
o Remote control function manages exceptions during printing!
o Energy saving mode: Only 1KWH power consumption during night standby...
It can be used for teaching - training in 3D design and 3D printing, from elementary to high school! For small-scale mass production jobs, the desired quantity production in a short time with remote control: AD4
FF AD4 Software Tools and Capabilities
Summary
3D PRINTING DEVICE o Number of Extruders: 1 (Bowden)
o Extruder Diameter: 0.4mm (on product), 0.6/0.3mm (optional)
o Maximum Temperature for Extruder: 265℃/240℃
o Max Temperature for Platform: 110℃
o Print Speed: 10-150 mm/s
o Supported Filaments: ABS/PLA/PC/PETG/PLA- CF/PETG-CF
o Print Volume: 220*220*250mm
o Layer Resolution: 0.1-0.4mm
o Printing Accuracy: ±0.1 mm (100mm edge cube test)
o Positioning accuracy: X/Y-Axis: 0.011 mm; Z- Axis: 0.0025 mmo Device Size：500*470*540 mm
o Cargo Weight: 20kg
o Display: 4.3 Inch Touchscreen
o Camera: 1 Piece
o Air Filter: HEPA 13
o Internal Memory: YES
o Filament sensor: YES
o Fail-Safe Operation on Power Outage: YES
o Input Voltage: AC100-240V/DC
o Operation voltage/current: 24V/13.3A
o Power: 320WSOFTWARE OTHER o Data Transfer: USB Disk/ WIFI/ Ethernet, Cloud
o Software: Flashprint, Cura, Slic3r (adjustment required)
o Input file Format: 3MF/STL/OBJ/FPP/BMP/PNG/JPG/JPEG File
o Output File Format: GX/G File
o Operating Noise: <50dB
o Working Temperature: 15-30℃
o Filament: 1.75mm (1Kg)
o Table setting: No adjustment required (Leveling Free)
o Resume Printing From Where It Left Off: YES
o Remote Camera Monitoring: YES
o Language Support: EN / CN
o Warranty: 12 months
o Delivery time: immediate delivery from stock
o Spare parts support: yes ( robotsepeti.com )FlashForge Adventurer 3.0 vs Adventurer 4.0
Adventurer 3 Adventurer 4 Printing volume 150*150*150 mm 220*200*250 mm LCD touch screen 2.8-inch 4.3-inch Filament spool 500g 1000g Otomatic Printing Platform YES No need any adjustment Filament sensor YES YES Replacable printing platform YES YES Flexible printing plate YES YES - MAgnetic Attachment Ultra silent working YES 50db Resume printing NO YES Camera YES YES Time-lapse video NO YES WIFI YES YES Cloud printing YES YES Air Filter NO YES - Hepa 13 Fan YES YES Shipping Content
